实验台
产品介绍
实验台是现代化实验室的核心基础配套设备，是理化分析、生物检测、仪器放置、试剂操作的专用承载平台。产品采用防腐、承重、耐高低温结构设计，集成水、电、气、收纳多功能模块，可与通风柜、生物安全柜、洁净工作台等设备配套组合，搭建标准化、规范化实验室体系。产品严格遵循GB/T 3324-2017、JG/T 417-2013国家行业标准，广泛适用于各类科研、医疗、检测、生物医药洁净实验室。
Laboratory bench is the basic core equipment of modern laboratories. It provides anti-corrosion, heavy-load and high-stability working platform for physical and chemical analysis, biological testing and precision instrument placement. Equipped with complete water, electricity and gas
modules, it can form a standardized laboratory system together with fume hoods, biosafety cabinets and clean benches, fully compliant with national industry standards.
应用范围
广泛应用于生物医药GMP洁净实验室、医院检验科、PCR实验室、疾控中心、第三方环境/食品/水质检测机构、高校科研院校、化工新材料实验室、农林检测实验室、电子精密无尘实验室等场景，可满足试剂配制、样品消解、微生物培养、仪器检测、精密实验操作等全流程实验需求。
Widely used in biomedical GMP laboratories, hospital testing rooms, PCR laboratories, CDC, third-party testing institutions, university scientific research, chemical industry, agricultural testing and electronic dust-free laboratories, covering all kinds of conventional and high-precision experimental operations.
产品规格
1、标准操作高度：850mm（仪器台可定制900mm）
2、边台/仪器台标准深度：750mm
3、中央台标准深度：1500mm（双面操作）
4、单节标准长度：1200mm、1500mm、1800mm，可无限拼接延长
5、支持非标定制：特殊尺寸、加高加宽、加厚承重、特殊防腐材质均可定制
1. Standard operation height: 850mm (The instrument table can be customized to 900mm)
2. Standard depth of the side table/instrument table: 750mm
3. Standard depth of the central table: 1500mm (Two-sided operation)
4. Standard length of a single section: 1200mm, 1500mm, 1800mm, which can be infinitely extended by splicing
5. Support for non-standard customization: Special sizes, height and width increase, thickness increase for load-bearing, and special anti-corrosion
materials can all be customized
产品分类
1、按材质分类
全钢实验台：采用1.0–1.2mm加厚冷轧钢板，整体静电环氧树脂喷涂，承重强、抗腐蚀、不变形、使用寿命长，为医院、药企、第三方检测、GMP实验室主流标配。
钢木实验台：加厚方钢框架+环保柜体板材，结构稳固、性价比高，满足常规教学、普通理化、环境检测等基础实验室使用需求。
PP聚丙烯实验台：一体式PP防腐材质，耐氢氟酸、浓强酸、强腐蚀试剂，专为高腐蚀化学实验室定制。
不锈钢实验台：304/316不锈钢材质，无缝一体、易清洁、耐反复消杀，适配微生物实验室、无菌洁净车间、医疗洁净场景。
2、按布局分类
中央实验台：实验室中心摆放，双面操作，可配备试剂架、水槽、插座，适用于多人同步实验、高通量检测场景。
边台实验台：靠墙单侧操作，布局规整，适配通风柜配套工位、常规样品前处理操作。
转角实验台：90°转角结构，合理利用实验室死角空间，优化
整体布局美观度与实用性。
仪器实验台：加厚承重台面、配置减震结构，专为色谱仪、质谱仪等大型精密实验仪器设计。
1.Classified by material
All-steel bench: Made of thickened cold-rolled steel with epoxy electrostaticspraying, high load-bearing, corrosion resistance and long service life,widely used in medical, pharmaceutical and GMP laboratories.
Steel-wood bench: Steel frame + environmental board, cost-effective andstable for general teaching and chemical laboratories.
PP bench: Integrated polypropylene material, ultra anti-corrosion, speciallyused for hydrofluoric acid and strong acid experiments.
Stainless steel bench: 304/316 material, easy to disinfect, suitable formicrobial laboratories and cleanrooms.
2. Classified by layout
Central bench: Double-sided operation for multi-personhigh-throughput experiments.
Wall side bench: Single-side operation, matched with fume hoodstations.
Corner bench: Optimize laboratory space layout.
Instrument bench: Reinforced heavy-duty platform with shockabsorption for precision instruments.
产品特征
01超强防腐耐候台面：可选实芯理化板、环氧树脂板、陶瓷板、PP板，耐酸碱、耐有机溶剂、耐高温、防渗色，满足各类化学实验腐蚀需求。 High anti-corrosion worktop: Optional phenolic, epoxy, ceramic and PP tops, resistant to acid, alkali, solvent and high temperature. | 02稳固承重结构：加厚钢材框架，焊接牢固、承重能力强、长期使用不变形、不晃动，仪器专用台面可承载重型设备。 Stable heavy-load structure: Thick steel frame ensures strong bearing capacity and no long-term deformation. |
03安全人性化设计：台面圆弧倒角防磕碰，柜门缓冲静音铰链，防水防漏电结构，水路防回流设计，实验操作更安全。 Safe & humanized design: Round anti-collision corners, silent buffer hinges, waterproof and anti-leakage structure. | 04多功能集成配置：可按需加装试剂架、PP水槽、三联水嘴、气体考克、防水插座、储物抽屉、落地试剂柜，功能齐全。 Complete functional configuration: Support reagent shelf, water sink, gas valve, waterproof socket and storage combination. |
05可调水平减震系统：配备不锈钢升降可调脚，适配地面平整度；仪器台可选专用减震脚垫，保护精密实验设备。 Leveling & shock absorption: Adjustable stainless steel feet and optional shock pads for precision instruments. | 06模块化拆装结构：分体式组装设计，搬运便捷、安装快速、可自由拼接延伸，适配新建实验室及老旧实验室改造项目。 Modular assembly: Split structure for easy transportation, fast installation and flexible layout. |
